Features
Mercedes derived, Highly FM 2.6 CR Power train
Synchromesh G-32 Gear Box for Effortless Gear Shifting
Monocoque body ensures total safety and car like ride quality
C.E.D. Primer Application and Robotic Top Coat painting for Paint Gloss Retention
Twin Blower AC for uniform and better climate control (optional)
Luxurious high back Recliner seats with Armrest (optional)
Technical Specification
| engine | |
|---|---|
| Type | 5 Cylinder Common Rail |
| Max. Torque | 320 NM @ 1400 - 2400 rpm |
| Displacement | 3245 Cc |
| Max. Engine Output | 114hp (85KW) @ 2800 rpm |
| transmission | |
|---|---|
| Type | Manual,Synchromesh |
| No. of Gear | 5 Forward + 1 Reverse |
| axles | |
|---|---|
| Rear | Live Rigid |
| Front | Dead Rigid |
| steering | |
|---|---|
| Type / Description | Power Steering |
| body | |
|---|---|
| Type | Monocoque Construction |
| suspension | |
|---|---|
| Front & Rear | Spring Semi-elliptical |
| Anti roll bar | Front-Yes, Rear-Yes |
| Shock absorbers | Hydraulic telescopic double acting at front and rear |
| TURNING RADIUS | |
|---|---|
| Wheels & Tyres | 215 / 75 R 15 |
| brakes | |
|---|---|
| Type | Dual circuit, Hydraulic, vacuum assisted, ABS with EBD |
| Front & Rear | Disc |
| Parking brake | Mechanical acting on rear wheel Transmission |
| Auto Slack Adjuster | yes |
| fuel tank | |
|---|---|
| Capacity (l) | 70 ltrs |
| dimensions (MM) | |
|---|---|
| Wheel base | 4020 |
| Overhang Rear | 1850 |
| overall Width | 2225 |
| Overall Height | 2670 (2870 with AC) |
| Overall Length | 6770 |
| Overhang Front | 900 |
| Ground Clearance | 190 |
| weight (kg) | |
|---|---|
| Maximum FAW | 2080 |
| Maximum GVW | 5750 |
| Maximum RAW | 3670 |
